9
Protein
Measurement
modes
Direct UV
Other
Beam height
15mm
Light source Tungsten and Deuterium lamps
Outputs USB, Parallel (Printer)
Power 110/220V AC 50/60Hz
Size (w x d x h) 600 x 450 x 260mm
Weight 22kg
SECTION 2 – Installation
2.1 UNPACKING
Remove the 6850 from the packaging and ensure the following items are included:
1. Model 6850 spectrophotometer fitted with 10 x 10mm cuvette holder (685-SC)
2. Power supply cables HH179(S) – UK lead
HH180(S) – EU lead
CABLEUS – US lead
3. Instruction manual (685 030)
4. 10mm Glass Cuvettes x 4 (035 027)
5. 10mm Quartz Cuvettes x 2 (035 028)
6. Dust Cover (685 040)
7. PC software CD and USB security dongle (685 035)
2.2 INSTALLATION
The 6850 is supplied ready to use.
The working temperature and humidity range of the 6850 spectrophotometer is 15 – 35˚C, 15 – 70%
relative humidity. The storage temperature and humidity range of the 6850 spectrophotometer is -10
– 50˚C, 15 – 70% relative humidity.
The unit should be placed on a clean flat surface which is free from drafts and vibrations. The units
are designed for operation on 110V±11V / 60Hz±1Hz and 220V±22V / 50Hz±1Hz AC.
Connect the power supply unit to the power inlet socket on the rear panel of the instrument and
connect to the mains socket. Turn the power on at the mains and switch the instrument on using the
power switch on the rear of the instrument.
