10
The instrument will initially perform several power-on tests before displaying the warm up screen:
Fig 2.2 – Instrument power-on tests complete
The power-on tests comprise
1. Lamp test
2. Detector test
3. A to D converter test
4. Grating position check
5. Dark current check
2.3 DISPLAY
The instrument has an inclusive display which enables text and graphs to be displayed clearly.
Following successful completion of the power-on tests and the instrument warm up time, the main
menu screen will be displayed:
Fig. 2.3 – Display
Main menu options
1. Photometrics measurement mode 5. DNA/Protein measurement mode
2. Quantitation measurement mode 6. Multi-wavelength measurement mode
3. Spectrum measurement mode 7. Instrument settings menu
4. Kinetics measurement mode 8. Slit width
