Light Tower Cable Wiring Overview
The light tower is not polarity sensitive and can be wired one of two ways:
1. The common wire connected to POWER and the other wires switched by relay to
GND.
2. The common wire connected to GND and the other wires switched by relay to
POWER.
All of the examples provided in this document use the first method. If you want to install
additional accessories with the light tower, the second method might be used. Consult
a qualified technician for additional configurations.
Cable Wire Colors
Wire Color Function
Blue Common
Black Green Light
Brown Yellow Light
White Red Light
Gray Audible Indicator
Installation Procedure
Refer to the Con TROLL PRO Installation Manual as needed.
1. Install the light tower using the supplied bracket, making sure the cable reaches the
Con TROLL PRO without strain.
2. Disconnect power from the Con TROLL PRO.
3. Loosen the four screws on the front panel and open the front panel.
4. If necessary, remove a wiring port plug on the Con TROLL PRO and replace it with
a dome connector.
5. Insert the light tower cable and pull it inside the enclosure far enough for the wires to
reach the terminal block without strain.
6. Tighten the dome connector to seal the enclosure and to provide strain relief for the
cable.
7. Wire the light tower cable according to the appropriate diagram for the intended
application. See pages 4 through 7.
8. Trim the exposed ends of any unused light tower wires.
9. Secure unused light tower wires to the light tower cable with zip ties.
