1. Minimize the Win-Situ Software.
2. Click the Windows Start button, and open the Control
Panel.
3. Double-click the System icon. Click the Hardware tab,
and open the Device Manager.
4. Click the plus sign next to Ports (COM and LPT), and
locate the USB Serial Port listing. The number listed
next to this entry is your COM port address.
Once you have determined the correct COM port
address in your operating system, reopen Win-Situ 5
Software. The following steps apply for all Windows
operating systems.
5. Close any open windows in Win-Situ Software.
6. Click Preferences.
7. Click Comm Settings, and then click the Port Number
menu.
8. Scroll down to find the correct COM port address. Click
the check mark to accept the changes.
9. Click the yellow Connect button in the lower right corner
to establish a connection to the instrument.
