BASIC MEASUREMENT
9
Manual ranging To select the measurement range
manually, press the Up/Down
keys.
For further details, see the Voltage or Current section of the Basic
Measurement chapter in the user manual
Resistance
Measurement item: 2W resistance, 4W resistance
1. Connect the
test leads
2W resistance 4W resistance
2. Press the
measurement
key
Press the measurement keys on the front panel. The
measurement result will appear on the display.
2W resistance 4W resistance
x 2 (twice)
S 4W 2W
2W, 4W
Automatic
ranging
Refresh
rate
Unit
Selected
range
AUTO
k
Manual ranging To select the measurement range
manually, press the Up/Down
keys.
For further details, see the Resistance section of the Basic Measurement
chapter in the user manual
