GDM-8261 Quick Start Guide

12

Compare*

SHIFT/ EXIT

The Compare
measurement checks and
updates if the
measurement data stays
between the upper (high)
and lower (low) limit
specified.

Math*

SHIFT/ EXIT

2/4W

MATH

Math measurement runs
four types of
mathematical operations,
MX+B, 1/X, Percentage
and Statistic, based on
the other measurement
results.

For further details see the Advanced Measurement chapter in the user
manual.
*Please see the Advanced Measurement chapter for operation details.

Basic + Advanced Measurement Combinations

Advanced
Measurement

Basic Measurement

AC/DCV

AC/DCI 2/4W Hz/P TEMP

dB

● — — — — —

dBm

● — — — — —

Max/Min

● —

Relative

● —

Hold

● —

Compare

● —

Math

● —
