GUT-6000A USER MANUAL
4
FEATURES
● Reliable desktop design.
● User’s friendly set up and operates.
● 16*1 character 9*7 dot matrix LCD display.
● Built in 6 functions and 10 numerical keys.
● Identifier over 1800 CMOS/TTL digital ICs (up to 24 pins).
● High test speed at an average 0.8 second for one IC test.
● The following IC series can be tested under 5V.
■ Texas Instruments 54/74 TTL series.
■ Motorola 14000 and RCA CD4000 CMOS series.
■ Other compatible ICs with the above mentioned devices.
● ''AUTO'' function key supports ''auto search and test'' function. User only to put
the IC into the socket, no need to press any key, no need to process any other
movements, the ''auto search and test'' will continue processing.
● ''LOOP'' function key supports ''continue examining'', able to make sure
reliability of the IC.
● Various ''BUZZER'' sounds to presents the test results ''FAIL'', or ''PASS''.
