25
l When continuity testing has been completed, disconnect the connection between
the testing leads and the circuit under test.
Measurement Operation (13)
F. Temperature Measurement (see figure 6)
To avoid harms to you or damages to the
Meter, please do not attempt to input
voltages higher than 60V in DC or 30V in AC.
Warning
The Temperature measurement range is -40
o
C
~1000
o
C or -40
o
F~1832
o
F. To measure
temperature, connect the Meter as follows:
1. Insert the red temperature probe into the
V
Ω
mA terminal and the black temperature
probe into the COM temperature.
( figure 6)
Model GDM-350A: OPERATING MANUAL
