13
A. DC Voltage Measurement (see figure 2)
Warning
To avoid harms to you or damages to the Meter from electric shock, please do
not attempt to measure voltages higher than 500V although readings may be
obtained.
The DC Voltage ranges are: 200mV, 2000mV, 20V,
200V and 500V. To measure DC voltage, connect
the Meter as follows:
1. Insert the red test lead into theV
Ω
mAterminal
and the black test lead into the COM terminal.
2. Set the rotary switch to an appropriate
measurement position in V range.
3. Connect the test leads across with the object
being measured.
The measured value shows on the display.
(figure 2)
Model GDM-350A: OPERATING MANUAL
Measurement Operation(1)
