Amplitude Specifications

Reference Level
Input Range

+20 to -40dBm

Accuracy

Within ±2dB
(1GHz);SPAN:5MHz

Unit

dBm, dBV, dBµV

Average Noise Level
≤ -100dBm
(typical, center frequency : 1GHz RBW : 30kHz)

Frequency Characteristics
within ±3.0dB @300MHz~2.6GHz,
within ±6.0dB @ 80~300MHz, 2.6~3GHz

Input
Input Impedance

50ohm, nominal

Input VSWR

less than 2.0@input att≥10dB

Input damage level

+30dBm (CW average
power), 25VDC

Input connector

N connector

Sweep Specifications

Sweep Time

Range

300ms to 8.4s, auto
(not adjustable)

Accuracy

within ±2% ( frequency
span : full span)
