GDP-050 Bandwidth DC-50MHz (-3dB)for x200, x500, x1000
DC-25MHz (for attenuation x100)
Attenuation X100, x200, x500, x1000
Accuracy ± 2%
Voltage Input
Range (DC+AC
peak to peak)
≤ 700Vp-p for x100 (؆230Vrms)
≤ 1400Vp-p for x200 (؆460Vrms)
≤ 3500Vp-p for x500 (؆1140Vrms)
≤ 7000Vp-p for x1000 (؆2300Vrms)
Permitted Max
Input Voltage Max differential voltage: 7000 V (DC+AC
peak to peak)
Max voltage between each input terminal
and ground: 6500 Vrms
Input Impedance Differential: 54MΩ/1.2pF
Between terminals and ground:
27MΩ/2.3pF
Output ≤ ±7.0V
Output
Impedance
50Ω
Rise Time 7ns for x200, x500 and x1000; 14ns for
x100
Rejection Rate on
Common Mode 60Hz: >80dB; 100Hz: >60dB; 1MHz:
>50dB
Power Supply External 9V DC power supply
Consumption 200mA max
Environmental
Operating
Conditions Indoor Use only.
Temperature: Reference: +20˚C to
+30˚C; Use: 0˚C to +50˚C; Storage: -30˚C
to +70˚C
Relative Humidity: Reference: ≤70%;
Use: 10% to 85%: 10% to 90%
Storage: 10% to 90%
Dimensions and
Weight
240mm x 80mm x 30mm: 280g
Electrical Safety to
IEC 1010-1 Dual Insulation
Installation Category III
Degree of Pollution 2
Rated Voltage or Max Line-Earth:
6500Vrms
