GW Instek GDS-3000 Series GDP-025/050/100 differential probe User Manual User Manual
Page 12
GDP Series User Manual
12
Input terminals
Category III input terminals.
Power Indicator
The power indicator lights when the external
power supply is connected.
Over range
indicator
The over range indicator lights when the input
voltage exceeds rating.
Power supply
input
External power supply input. 9V, 200mA.
Output
Differential probe output.
≤±7V into 1MΩ.
