Table 1 Exception Codes
Exception
Code
Name Meaning
01 Illegal Function
Unsupported function code. Only 03, 06 and 16 are
supported.
02 Illegal Data Address
Invalid register address detected. If any request for registers
outside of the valid register address for the CXT occurs, this
exception code will be returned.
There are other exception codes defined in Modbus™ but these are the only ones used by the CXT.
NOTE: When using Detcon controllers, Modbus exceptions should be turned off.
4.1.2 Modbus™ Broadcast Requests
The Modbus™ broadcast request was introduced in the CXT to support commands to be executed across all
CXT transceivers simultaneously. More specifically this is used to place all CXTs in a low power state for a
specified time to conserve battery life. Only the transceivers (radio) are placed into a low power state, the
CXT sensor will continue to operate normally. If none of the CXTs are battery powered then there is no need
to issue a command to place the transceivers in low power mode.
According to the Modbus™ specification a broadcast request is defined as a request with the Address Field set
to 0 and is used for writing only. There is no response returned as with normal Modbus™ transactions since
all devices on the system are accessed at the same time. Both Function Codes 06 and 16 (writes) are supported
with a broadcast request on the CXT.
Since there is no response on the broadcast request, there is a requirement to wait for a period of time before
sending out the next request. This allows all slave devices to process the command before the next request is
received. This is defined as the “turnaround delay”. This turnaround delay should be approximately 150
milliseconds for broadcast requests sent to the CXT. Controllers in general can meet this timing because it
takes longer than this to generate the next request so it may be unnecessary to make any adjustments to meet
this timing.
NOTE: Controllers that generate Modbus™ broadcast requests to the CXT must ensure a
turnaround delay of 150ms is met otherwise the next request can cause the broadcast request to
be overwritten and ignored.
Broadcast requests are not confined to commands to put the network in low power mode, but can be used
where any normal write command is used.
4.2 Modbus™ Register Map & Description
When the CXT is assigned a Modbus™ address, the following registers become available to the controller for
access. All CXT sensors implement this register set. Some registers are Read Only (R) and others are
Read/Write (R/W) as shown by the R/W column. This equates to specific function codes where Read is
function code 03 and Write is function code 06 or 16.
NOTE: A write to a Read Only register is allowed and returns a response, but it does not
change the value of the register. In some devices this would return an exception code.
The following table is the register map for the CXT sensor and gives a brief description each register or
register set. This information is only meant as a reference. The registers are divided into two sections, one for
