Model CX-DM
Width: 2.2 inches (55 mm)
Weight:
2.5 lbs (1.2 Kg)
Mechanical Connection:
¾” Male NPT threaded connection with locking nut
Electrical Connection: five 18 gauge wire leads - 5.5” long
8.2 Sensor Specific Data
Table 3 Sensor Specific Data
Gas GasName Part Number
1
Response
Time
(seconds)
SpanDrift
Temperatur
e Range °C
Humidity
Range%
Warranty
O
2
Oxygen 371-343400-025 T95<30 <5%signal loss/year -20 to+50 15 to 90 2 years
C
2
H
3
O Acetaldehyde 371-12EA00-100 T90<140 <5%signal loss/year -20 to+50 15 to 90 2 years
C
2
H
2
Acetylene 371-12EG00-100 T90<140 <5%signal loss/year -20 to+50 15 to 90 2 years
NH
3
Ammonia 371-171700-100 T90<90
<2%signal
loss/month
-20 to+50 15 to 90 2 years
AsH
3
Arsine 371-191900-001 T90<60
<5%signal
loss/month
-20 to+40 20 to 95 1.5 years
Br
2
Bromine 371-747500-005 T90<60
<2%signal
loss/month
-20 to+50 15 to 90 2 years
C
4
H
6
Butadiene 371-12EB00-100 T90<140 <5%signal loss/year -20 to+50 15 to 90 2 years
CO
Carbon
Monoxide
371-444400-100 T90=30 <5%signal loss/year -40 to+50 15 to 90 3 years
Cl
2
Chlorine 371-747400-010 T90<60
<2%signal
loss/month
-20 to+50 15 to 90 2 years
ClO
2
(>10ppm) Chlorine Dioxide 371-777700-001 T90<60
<2%signal
loss/month
-20 to+50 15 to 90 2 years
ClO
2
(<=10ppm)
Chlorine Dioxide 371-282800-050 T90<120
<1%signal
loss/month
-20 to+40 10 to 95 2 years
B
2
H
6
Diborane 371-192100-005 T90<60
<5%signal
loss/month
-20 to+40 20 to 95 1.5 years
C
2
H
5
OH Ethanol 371-12EO00-100 T90<140 <5%signal loss/year -20 to+50 15 to 90 2 years
C
2
H
5
SH Ethyl Mercaptan 371-24EZ00-100 T90<45
<2%signal
loss/month
-40 to+50 15 to 90 2 years
C
2
H
4
Ethylene 371-12ED00-100 T90<140 <5%signal loss/year -20 to+50 15 to 90 2 years
C
2
H
4
O Ethylene Oxide 371-12EJ00-100 T90<140 <5%signal loss/year -20 to+50 15 to 90 2 years
F
2
Fluorine 371-272700-001 T90<80 <5%signal loss/year -10 to+40 10 to 95 1.5 years
CH
2
O Formaldehyde 371-12EP00-100 T90<140 <5%signal loss/year -20 to+50 15 to 90 2 years
GeH
4
Germane 371-232500-002 T90<60
<1%signal
loss/month
-20 to+40 20 to 95 1.5 years
N
2
H
4
Hydrazine 371-262600-001 T90<120
<5%signal
loss/month
-10 to+40 10 to 95 1 year
H
2
(ppm) Hydrogen 371-848400-100 T90=30
<2%signal
loss/month
-20 to+50 15 to 90 2 years
H
2
(LEL)* Hydrogen 371-050500-04P T90<60
<2%signal
loss/month
-40 to+40 5 to 95 2 years
HBr
Hydrogen
Bromide
371-090800-030 T90<70
<3%signal
loss/month
-20 to+40 10 to 95 1.5 years
HCl
Hydrogen
Chloride
371-090900-030 T90<70
<2%signal
loss/month
-20 to+40 10 to 95 1.5 years
HCN
Hydrogen
Cyanide
371-131300-030 T90<40
<5%signal
loss/month
-40 to+40 5 to 95 2 years
1 The last three digits of the Part Number are the range of the sensor cell. I.E. “-100” is a 100ppm range.
