Model CX-DM
Set Autospan Level
Set Modbus ID
Bump Test
Restore Defaults
Software Flowchart
dec
LEGEND:
PGM1 - Program Switch Location #1
PGM2 - Program Switch Location #2
(S) - Momentary Swipe
(M) - Momentary hold of Magnet during text
scroll until the ">" appears, then release
(3) - 3 second hold from ">" prompt
(10) - 10 second hold from ">" prompt
Auto Time-out - 5 seconds
inc - Increase
dec - Decrease
#, ##, ### - numeric values
AutoZero PGM1 (3)
PGM2 (10)
PGM2 (3)
inc
Auto Time-Out
View Sensor Status
PGM1/2 (3)
PGM1/2 (M)
PGM2 (S)
PGM1/2 (3)
PGM1 (S)
##
AutoTime-out
PGM1/2 (3)
PGM1/2 (M)
Set Detection Range
AutoSpan
Normal Operation
PGM1 (3)
Auto Time-Out Auto Time-Out
inc PGM2 (S)
PGM1/2 (3)
PGM1 (S)
##
PGM1/2 (3)
PGM1/2 (M)
Set Autospan Level
dec
inc
PGM1/2 (3)
PGM1 (S)
PGM2 (S)
##
dec
PGM1/2 (3)
PGM1/2 (M)
Set Modbus ID
Status is CX-DM V
Range ###
Autospan Level ##
Modbus ID ##
Tempcomp Level ##
Last Cal # Days
Sensor Life ###
Temperature ##
PGM1/2 (M)
Defaults Restored
PGM1/2 (3)
Restore Defaults
Auto Time-Out
dec
inc PGM2 (S)
PGM1/2 (3)
PGM1 (S)
##
AutoTime-out
PGM1/2 (3)
PGM1/2 (M)
Bump Test
Figure 12 Software flow chart
3.2 Normal Operation
In normal operation, the Intelligent Transmitter Module (ITM) display will be blank and will display the gas
reading once every 10 seconds for about 2 seconds (normally appear as "0"). At any time, swiping a magnet
across either PGM1 or PGM2 will cause the ITM to display the range and gas type (i.e. "ppm H2S"). If the
sensor is actively experiencing any diagnostic faults, a swipe of the magnet will cause the display to scroll the
fault condition. Refer to Section 5 Service and Maintenance for more information on fault conditions.
3.3 Calibration Mode
Zero and span calibration should be performed on a routine basis (quarterly minimum is advised) to ensure
reliable performance. If a sensor has been exposed to any de-sensitizing gases, or to very high over-range
CX-DM Instruction Manual Rev. 1.3 Page 13 of 40
