RXT-300 SmartWireless™

RXT-300 Wireless IM

Rev. 2.0

Page 30 of 41

Table 5 RXT-300 Register Map

Register

Access

Name

Description

0

R

Detcon Type

Detcon Register Type = 13 for RXT-300

1

R

Alarm 1 Output

Current Alarm 1 Output state (0 = Open, 1 = GND)

2

R

Alarm 2 Output

Current Alarm 2 Output state (0 = Open, 1 = GND)

3

R

Alarm 3 Output

Current Alarm 3 Output state (0 = Open, 1 = GND)

4

R

Alarm 4 Output

Current Alarm 4 Output state (0 = Open, 1 = GND)

5

R

4-20mA A

Reading for 4-20mA Sensor Input (A)

6

R

4-20mA B

Reading for 4-20mA Sensor Input (B)

7

R

Battery Life Percent

Battery Life remaining in %

8

R

Battery Life Minutes

Battery Life remaining in minutes

9

R

Battery Millivolts

Battery Voltage in Millivolts

10 – 15

--

Reserved

16

R

RXT-300 Count

Number of RXT-300s in System

17 – 18

--

Reserved

19

R

Sensor Count

Number of Sensors in System

20 – 44

--

Reserved

45

R

uC F/W Version

Microcontroller Firmware Version

46

R

uC F/W Month/Day

Microcontroller Firmware Month / Day

47

R

uC F/W Year

Microcontroller Firmware Year

48

R

Radio F/W Version

Radio Firmware Version

49

R

Radio F/W Build

Radio Firmware Build

50

R

Radio S/W Version

Radio Software Version

51 – 66

--

Reserved

67 R/W

Control

Control

Register

51 – 71

--

Reserved

72 R

Status

Status

Register

73 – 98

--

Reserved

99

R

Timestamp Secs Hi

Time from Startup – Seconds High

100

R

Timestamp Secs Lo

Time from Startup – Seconds Low

101

R

Timestamp MSecs

Time from Startup – Milliseconds

102 – 4418

--

Reserved

5.3.1 Register – Detcon Type

The Detcon Type is a unique identifier of the type of device and associated register map. A controller can
therefore perform a search and determine what Detcon devices are present on a Modbus™ system. A
controller can look for this value when search Modbus™ addresses 161 to 192 to find the Modbus™ address
of the RXT-300 that it is attached to.

5.3.2 Register – Alarm Outputs

There are four registers that give the status of the four open collector Alarm Outputs. A value of 0 denotes the
Alarm Output is not grounded and a value of 1 or non-zero value denotes the Alarm Output is grounded. The
default value for all Alarm Outputs upon power up or reset is 0.
