Avigilon Control Center System Integration Guide with Gallagher Command Centre

7

2. Right-click the camera associated with an alarm and select Properties.

3. Select the Trigger-Output tab.

4. Open the Hardware Master List Window.

5. From the Hardware Master List Window, drag the output that will trigger the alarm into

the Trigger—Outputs tab in the Properties dialog box.

Outputs can include magnetic locks, alarm bells, or warning lights. A change in any of
the outputs will send a FTCAPI string that can be used to trigger or acknowledge an
Avigilon alarm.

6. Click OK.

7. In the Hardware Master List Window, right-click the selected output and select

Properties.

8. Select the Messages tab.
