IOSK
I
NSTALLATION
P
ROCEDURES
Follow these steps to install the
SuperScrip pedestal unit:
1. Select a mounting location for the
SuperScrip Kiosk pedestal. Place the
unit at this location (See Figure 1).
Make sure there are no obstructions
that would limit access to the unit.
There should be convenient access
to an AC power outlet and telephone
jack.
2. Remove the lower sign panel. The
lower sign panel is held in place by a
securing plate, which must be re-
moved first, as shown in Figures 2a
and 2b. Note the two screws that
secure the plate to the kiosk pedes-
tal frame.
Once the plate has been removed,
the sign can be removed from the
cabinet, as shown in Figures 3a
through 3d.
Fig. 1
Fig. 2a
Fig. 2b
Observe ALL safety precautions for
operating hand and power tools! Wear
eye protection while operating the elec-
tric drill and while using the hammer to
drive anchor spikes into the floor!
TOOL USE/SAFETY
ELECTRICAL/MECHANICAL
SAFETY
Observe ALL safety precautions for
electrical equipment. Exercise extreme
care and use proper lifting techniques
when moving heavy items!
