Tele Vue VIP-2010 Paracorr Type-2 User Manual
Page 2
PARACORR TYPE 2 EYEPIECE POSITION CHART
Position
A
B
C
D
E
F
G
H
2" Oculars
(Dist. from Ref.)
-0.4"
-0.3"
-0.2"
-0.1"
0"
+0.1"
+0.2"
+0.3"
31 N T5
17 Ethos
21 Ethos
22 N T4
17 N T4
26 N T5
35 Pan
20 N T5
41 Pan
27 Pan
13 Ethos
10 Ethos
3.7 & 4.7 Ethos
(w/incl. adptr)
1¼" Oculars
(Dist. from Ref.)
0"
+0.1" +0.2"
+0.3"
+0.4"
+0.5"
+0.6"
+0.7"
17.3 Delos
14 Delos
8 Ethos
6 Ethos
32-to-8 Plössls
Radians (all)
24 &19 Panoptic
12-to-3.5 Delos
14* & 17.3* Delos
(*with AIT-2125
In-Travel Adapter)
12 Nagler Type 4
16 Nagler Type 5
Nagler Type 6 (all)
2-4 & 3-6 Nagler Zooms
3.7 & 4.7 Ethos
40 Plössl
"A" Position
"E" Position
(neutral offset)
"H" Position
2" to 1¼"
adapter
Tunable Top
Paracorr Type 2
Lens Assembly
*
*
Do not lay lens assembly
down on the flange side:
the Paracorr lens protrudes
and can be scratched.
