Star Water Systems HSP20P1 - Manual (Page 13)

13
PUMP INSTALLATION FOR WELL ANd SURFAcE WATER
6. Connect the 1-1/2 in. outlet pipe to the
sprinkler system (not included) by gluing in
additional sections of pipe (not included) as
needed.
7. Connect union to ensure proper fit. Do not
tighten until after priming.
cAUTION: Do not glue union together.
IL1123
Outlet Pipe
Inlet
Pipe
Discharge to
Sprinkler System
IL1124
Outlet Pipe
Inlet
Pipe
Discharge to
Sprinkler System
6
7
