SEED HAWK® TOOLBAR OPERATOR’S MANUAL 22
3.5 45 SERIES TOOLBAR DIMENSIONS
10” (254 mm) Row Spacing
Tool Bar Width
ft‐in (m)
Number of Seed
Rows
Number of
Sections
*Folded Width ft (m) *Folded Height ft (m)
30’ (9.15 m) 36 3 14’ 8” (4.47 m) 13’ 0” (3.96 m)
40’ (12.19 m) 48 5 14’ 8” (4.47 m) 14’ 7” (4.46 m)
50’ (15.24 m) 60 5 14’ 8” (4.47 m) 14’ 7” (4.46 m)
60’ (18.29 m) 72 5 14’ 8” (4.47 m) 16 ’8” (5.08 m)
12” (305 mm) Row Spacing
Tool Bar Width
ft‐in (m)
Number of Seed
Rows
Number of
Sections
*Folded Width ft (m) *Folded Height ft (m)
30’ (9.15 m) 30 3 14’ 8” (4.47 m) 13’ 0” (3.96 m)
40’ (12.19 m) 40 5 14’ 8” (4.47 m) 14’ 7” (4.46 m)
50’ (15.24 m) 50 5 14’ 8” (4.47 m) 14’ 7” (4.46 m)
60’ (18.29 m) 60 5 14’ 8” (4.47 m) 16 ’8” (5.08 m)
15” (381 mm) Row Spacing
Tool Bar Width
ft‐in (m)
Number of Seed
Rows
Number of
Sections
*Folded Width ft (m) *Folded Height ft (m)
30’ (9.15 m) 25 3 14’ 8” (4.47 m) 13’ 0” (3.96 m)
40’ (12.19 m) 33 5 14’ 8” (4.47 m) 14’ 7” (4.46 m)
50’ (15.24 m) 41 5 14’ 8” (4.47 m) 14’ 7” (4.46 m)
60’ (18.29 m) 49 5 14’ 8” (4.47 m) 16 ’8” (5.08 m)
*FOLDED WIDTH AND HEIGHT CAN BE REDUCED BY REMOVING WING
TIRES.
