Appendix A: Specifications and Parameter
Settings
Temperature Range Designed for Flares/Pilots of any intensity
Working Distance 0 - 1320 ft. (0 - 400m)
Response Time 100 mSeconds
Outputs Red and Green status lights, mA and set point relay contacts
Relay Contacts 120Vac 0.5A , 24Vdc 1A , Resistive
Sensitivity
Adjustment
0 - 1 VDC
Focusing Range 20 in. (51cm) to infinity
Sighting Visual aiming
Target Size
(Field of View)
S (dia. of circle) = D (Distance)/37.5, 60, 75, 150, or 300
Power Ratings
115 ± 5%, 50/60 Hz (standard)
220 ± 5%, 50/60 Hz (optional)
24V +/-20%, (optional)
115 Watts
Fusing
ELECTRONICS:
115 .250A,’T’ Time-Lag 5x20 Little fuse type 218.250
220 .125A,’T’ Time-Lag 5x20 Little fuse type 218.125
24V
1A,’T’ Time-Lag 5x20 Little fuse type 218.001
6 882 480 Fuse, 1 A (24 VDC), (P/N 15825-1000)
6 882 490 Fuse, 4 A (24 VDC), (P/N 19154-4)
6 882 500 Fuse, 1 A (115 VAC), (P/N 19154-1)
6 882 510 Fuse, 1/4 A (115 VAC), (P/N 19534-0250)
6 882 520 Fuse, 0.5 A (230 VAC), (P/N 19154-0.5)
6 882 530 Fuse, 125 mA (230 VAC), (P/N 19534-0125)
HEATER :
115 1A, Fast TR5, Wickman 370-1100
220 .5A, Fast TR5, Wickman 370-0500
24V
4A, Fast TR5, Wickman 370-1400
Ambient Temperature
Limits
A. 40 to 120 °F (4 to 50 °C) with no cooling
B. 40 to 200 °F (-40 to 80 °C) with cooling base, 10 GPH water flow
at 60 O F (15 ° C).
C. 40 to 175 °F (-40 to 80 ° C) with vortex air cooler (optional) with
100 psig source.
D. Both cooling methods can accommodate higher ambient
temperature by increasing flow rates. Consult factory.
