Chapter 10: appendix, 1 system connection diagram – LT Security LTD9056M6 User Manual
Page 28
User Manual
26
Chapter 10: Appendix
10.1 System connection diagram
10.2 Accessories
Power Cord
Design may vary depending
on country
Power Adaptor
User’s Manual
Software CD
Remote Controller
USB Cable (For
PC Backup Only)
LAN(RJ-45)Port on DVR
Camera
Sensor
Alarm
PC(Optional)
VCR
TV or Monitor
USB
DVR
