5.8 Sensor Setup
CONT: Continuous alarm until any key is pressed.
OFF: No alarm
Note : Sensored Record Time and Alarm On Time are measured in seconds
5.9 H/W Sensor Setup
Note: Sensors and extension alarm are not included with the DVR system and may be purchased
separately.
Note: For 4-ch DVR, there are 4CH inputs of the sensor
For 9-ch DVR, there are 8CH inputs of the sensor
5.10 Motion Detector Setup
This section allows you to set up motion detection options for each camera.
Sensored Record Time indicates how long the
recording time is when the motion or sensor is
triggered.
Alarm On Time indicates whether the buzzer
will sound when motion is detected.
Hardware Sensor Setup:
There are 3 different modes for sensor setting: NOT
INSTALLED, NORMAL-CLOSE and
NORMAL-OPEN. Consult the alarm purchased for more
details on which setting is required.
Motion Detector Setup:
ON/OFF: Enable or disable motion detection
recording.
LEVEL: Sensitivity for motion detection. There are 3
levels sensitivity: Level 1-low, level 3- highest
AREA: Select detectable area on the screen.
H/W SENSOR SETUP
CHANNEL-1 TYPE:NORMAL-OPEN
CHANNEL-2 NOT INSTALLED
CHANNEL-3 NOT INSTALLED
CHANNEL-4 NOT INSTALLED
( )MOVE (SEL)SELECT (MENU)EXIT
SENSOR SETUP
SENSORED RECORD TIME 30
ALARM ON TIME OFF
H/W SENSOR SETUP
MOTION DETECTOR SETUP
( )MOVE (SEL)SELECT (MENU)EXIT
MOTION DETECTOR SETUP
CH1 ON LEVEL1 AREA
CH2 ON LEVEL2 AREA
CH3 ON LEVEL2 AREA
CH4 ON LEVEL2 AREA
( )MOVE (SEL)SELECT (MENU)EXIT
