42
Digital Video Recorder User Manual
Fig 4-37 P.T.Z configuration-advance
Step2: in the Advance interface, after clicking preset “Setting” button, a dialog box will pop-up as Fig 4-38:
Fig 4-38 advance-preset setting
a. in the preset set interface, click Setting button to see a window as Fig 3-39:
Fig 4-39 preset set-setting
b. user can control the dome rotates up, up left, down, right down, left , left down, right and up right and stop rotating; adjust the
rotate speed and the value of zoom, focus and iris of the dome;
c. select the serial number of the preset point. Click
button to enable the PTZ wiper and click
button to enable the
