21
Digital Video Recorder User Manual
4.3 Record configuration
Record configuration includes six sub menus: enable, record bit rate, time, recycle record, stamp and snap.
4.3.1 Enable
Step1: enter into system configuration record configuration enable; refer to Fig 4-11:
Fig 4-11 record configuration-enable
Step2: select record, audio and record time.
Step3: user can setup all channels with same parameters. Please tick off “all” to do relevant setup.
Step4: click “default” button to resort default setting; click “apply” button to save the setting; click “exit” button to exit current
interface.
4.3.2 Record stream
Step1: enter into system configuration record configuration record bit rate; refer to Fig 4-12:
Step2: setup rate, resolution, quality, encode and max bit stream
Step3: user can also setup all channels with same parameters.
Step4: click “default” button to resort default setting; click “apply” button to save the setting; click “exit” button to exit current
interface.
Note: if the rate value set is over high the maximum resources of the device, the value will be adjusted automatically.
Parameter Meaning
Record Record switch of every
channels
Audio Enable live record audio
