Digital Video Recorder User Manual
Step2: select split mode: 1
Ч1、2Ч2、2Ч3、3Ч3 and channel.
Step3: dwell time: the time interval for a certain dwell picture display switching to next dwell picture display
Step4: select the split mode and then setup current picture group. Click
button to setup the previous channel groups of dwell
picture. Click
button to set the latter channel groups of dwell picture.
Step5: click “default” button to resort default setting; click “apply” button to save the setting; click “exit” button to exit current
interface.
4.2.3 Spot
Step1: enter into system configuration
live configuration
Spot; refer to Fig 4-9:
Fig 4-9 live configuration-Spot
Step2: select split mode: 1
×1and channel
Step3: dwell time: the time interval for a certain dwell picture display switching to next dwell picture display.
Step4: select the split mode and then setup current picture group. Click
button to setup the previous channel groups of dwell
picture, click
button to set the latter channel groups of dwell picture.
Step5: click “default” button to resort default setting; click “apply” button to save the setting; click “exit” button to exit current
interface
