Page 49
43
Digital Video Recorder User Manual
Step3: select a date, press Search button and then click the time grid to set the play start time or input play record time manually.
The selected time match the blue grid.
Note: the vertical column means hours, horizontal column means channels.
Step4: click Play
button to playback record; click the relevant buttons on the screen to do operation:
Playback buttons
Note: when the monitor resolution is VGA800*600, the time search interface will appear a hide button. Click this button
and the whole interface can be expanded.
5.2 Event search
Step1: enter into Search configuration
event search; refer to Fig 5-2:
Fig 5-2 Search configuration-event search
