Lincoln Electric IM890 POWER MIG 140_180 - Manual (Page 47)

Center Panel Assembly, Includes: L12322 1 X • X
Center Panel Assembly, Includes: L12322-2 1 • X •
1 Center Panel L12321 1 X • X
1 Center Panel L12321-1 1 • X •
2 Bow Washer T10781-10 1 X X X
3 Wear Plate S18423-1 1 X X X
4 Spindle Shaft S24227 1 X X X
5 Spindle Spacer S24226 1 X X X
6 Wing Nut T9968-5 1 X X X
7 Plain Washer S9262-120 1 X X X
8 Lock Washer E106A-16 1 X X X
9 3/8-16 x .625 HHCS CF000018 1 X X X
10 Self Tapping Screw (Secures Center Panel to Chassis) S8025-101 6 X X X
11A Polarity Panel L12555-1 1 X X X
11B Output Stud S25937 2 X X X
11C 1/4-20 x .50 HHCS CF000012 2 X X X
Plain Washer (Not Shown) S9262-23 2 X X X
Lock Washer (Not Shown) E106A-2 2 X X X
11D Wing Nut T9968-6 2 X X X
12 Plug Button T10397-3 1 X X X
13 Plug Button T10397-19 1 X X X
15A By-Pass Assembly (Refer to Wiring Diagram) S22969-4 1 • X •
15B Ground Screw Asbly, Includes: S18922-8 1 • X •
15C Thread Forming Screw S9225-63 1 • X •
15D Plain Washer (Not Shown) S9262-27 2 • X •
15E #10-24 HN (Not Shown) CF000010 2 • X •
15F Lock Washer (Not Shown) E106A-1 1 • X •
15G Lock Washer T9695-1 1 • X •
16A By-Pass P.C. Board L10882-[ ] 1 • X •
16B Sems Screw T10082-27 2 • X •
17A Spot Timer & Spool Gun Decal (Not Shown) (Includes -A & -B) T13086-200 1 X X •
17A Spot Timer & Spool Gun Decal (Not Shown) (Includes -A & -B) T13086-213 1 • • X
05-25-2011
POWER MIG ® (140, 180 MODELS)
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-533-E.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-533-E.1
Note: When ordering new printed circuit boards indicate the dash number [ ] of the “Old” board
that is to be replaced. This will aid Lincoln in supplying the correct and latest board along
with any necessary jumpers or adapters. The dash number brackets [ ] have purposely
been left blank so as to eliminate errors, confusion and updates.
