Lincoln Electric IM890 POWER MIG 140_180 - Manual (Page 43)

1A Case Front G4812-1 1 X X X X X
1B Thread Forming Screw S9225-63 4 X X X X X
2 Nameplate (Code 11254) L12398-2 1 X • • • •
2 Nameplate (Code 11255) L12398-4 1 • • • • X
2 Nameplate (Code 11256) L12398-3 1 X • • • •
2 Nameplate (Codes 11257 & 11444) L12398-5 1 X • • • •
2 Nameplate (Codes 11804 & 11819) L13921-1 1 • X • X •
2 Nameplate (Code 11820) L13921-2 1 • • X • •
3A Knob S18425-1 2 X X X X X
3B Nut (Not Shown) T10940-10
As Req
X X X X X
3C Self Tapping Screw (Not Shown) S8025-96 2 X X X X X
3D Lock Washer (Not Shown) T9695-5 2 • X X X •
4 Switch T10800-59 1 X X X X X
5A Square Flange Female Receptacle (Part of Plug & Lead Asbly) S18657 1 X X X X X
5B Self Tapping Screw S8025-96 2 X X X X X
6 Control P.C. Board (Code 11254 & 11256) L12450-[ ] 1 X • • • X
6 Cntrl P.C. Bd (Codes 11255,11257,11444,11804,11819 &11820) L12230-[ ] 1 X X X X X
7A Handle M20483 1 X X X X X
7B Thread Forming Screw S9225-63 2 X X X X X
8 Case Back & Bottom G4718 1 X X X X X
9A Solenoid Assembly M17294-8 1 X X X X X
9B Plain Washer S9262-10 1 X X X X X
9C Lock Nut T14370-1 1 X X X X X
10 Circuit Breaker T12287-21 1 X • X • •
10 Circuit Breaker T12287-40 1 • X • X X
11A Power Cord (Not Shown) (Codes 11254, 11255 & 11819) S25563-3 1 X X • • X
11A Power Cord (Not Shown) (Codes 11256, 11257 & 11820) S15599-2 1 X • X • X
11A Power Cord (Not Shown) (Code 11444) S19836-7 1 X • • • X
11A Power Cord (Not Shown) (Code 11804) S25563-1 1 • • • X •
11B Lead Grommet (Codes 11254,11255,11256,11257,11804,11819 & 11820) T9274-11 1 X X X X X
11B Lead Grommet (Code 11444) S19999-2 1 X • • • X
12A Case Back (Codes 11254,11255,11256,11257,11804,11819&11820) G4813 1 X X X X X
12A Case Back Panel (Code 11444) G4813-1 1 X • • • X
12B Self Tapping Screw (Not Shown) S8025-101 4 X X X X X
13 Gas Hose T10642-217 1 X X X X X
14 Rating Decal (Codes 11254, 11255, 11804 & 11819) S26499-2 1 X X • X X
14 Rating Decal (Codes 11256, 11257 & 11820) S26499-3 1 X • X • •
14 Rating Decal (Code 11444) S26499-5 1 X • • • •
Grounding Screw Mounting Hardware:
16A Thread Forming Screw (Not Shown) S9225-63 1 X • • • X
16A Thread Forming Screw (Not Shown) S9225-76 1 • X X X •
16B #10-24 HN (Not Shown) CF000010 2 X X X X X
16C Lock Washer (Not Shown) T9695-1 1 X X X X X
Hardware to Secure Leads to Ground Screw:
17A #10-24 HN (Not Shown) CF000010 1 X X X X X
17B Lock Washer (Not Shown) E106A-1 1 X X X X X
17C Plain Washer (Not Shown) S9262-27 1 X X X X X
07-24-2012
POWER MIG ® (140, 180 MODELS)
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-533-C.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-533-C.1
Note: When ordering new printed circuit boards indicate the dash number [ ] of the “Old” board
that is to be replaced. This will aid Lincoln in supplying the correct and latest board along
with any necessary jumpers or adapters. The dash number brackets [ ] have purposely
been left blank so as to eliminate errors, confusion and updates.
#
