Connecting external inputs to the alert alarm, Figure 4 farm hand alert alarm, High temperature monitor – Hired-Hand Emergency Back-Up and Alarms: High Temperature Monitor Installation User Manual
Page 3
HIRED-HAND, INC.
• 1733 Co Rd 68 • Bremen, AL 35033 • Phone 256-287-1000 • Fax 256-287-2000
Manual Part No. 4801-5152 rev 8-03 Page
3 of 4
J8
J6
Internal Wiring
High Temperature
Monitor
Inset B
Inset A
Black
White
TEMPERATURE
PROBE
ALARM
WIRES
Au
x 2
Au
x 1
High Temperature Monitor
4501-6127
Rev 8-03
®
Bremen, AL
Ph. (256) 287-1000
Fax (256) 287-2000
Connecting External Inputs to the Alert Alarm
FIGURE 4
Farm Hand Alert Alarm
Inset B
Inset A
NOTE: The jumper across J6 and\or J8 must be removed if an
external alarm input is connected.
SIGNAL STATUS
Conditions Normal = N.C.
Alarm Conditions = N.O.
