Installation
1. Cut rough opening in wall.
54 3/4" Min. x 55 3/4" Min. (See Figure 4).
2. Place the Light Trap Air Inlet through the
opening and slide the Inlet through the opening
until the flange is against the wall (Figure 5).
3. Secure the Light Trap Air Inlet to the wall
with wood screws.
4. Installation complete.
Rough Opening
54 3/4" Min. X 55 3/4" Min.
Figure 4
This flange goes
against wall.
Figure 5
