STI UNIVERSAL STOPPER SERIES - Manual (Page 6)

Polycarbonate Cleaning Instructions
Rinse with water to remove abrasive dust and dirt. Wash with soap or mild detergent, using a soft
cloth. Rinse once more then dry with a soft cloth or chamois. Exercise caution when using water
inside enclosure. Make sure unit is completely dry inside before reassembling. To remove grease
or wet paint from exterior of cover, rub gently with a soft cloth thoroughly wetted with Naptha. Then
wash and rinse.
Do not use razor blades.
Gasket Installation
Use of gaskets is necessary to ensure a proper seal in weatherproof applications. The Universal
Stopper ships complete with all necessary gaskets and should be used accordingly. The Mounting
Gasket is included on all Universal Stopper products and is embedded in the STI factory prior to
shipping. Two 3” gaskets are shipped with the SURFACE mount Universal Stopper, refer to Step 8 in
the installation instructions. Each 3” gasket is intended to be used with the inserts also shipped with
the SURFACE mount Universal Stopper. To install, the insert should first be fitted in place in the correct
orientation. Then, overlap 1/8” of the existing Mounting Gasket on the Universal Stopper housing, run
the cord into the preformed channel until it overlaps 1/8” of the opposing Mounting Gasket.
Horn Battery Replacement and
Hi/Lo Volume Changing Instructions
1. Obtain the Universal Stopper Service Pin, a small Phillips screwdriver, a 3/32” allen wrench (if
desired) and replacement 9V battery.
2. Open the Universal Stopper cover. The horn should sound. Insert the Service Pin into the Service
Pin Receptor. The horn should silence.
3. (If desired) While holding the horn with one hand, remove the button head screw on the front of the
cover. Then, perform the following actions with the horn separately.
4. Use the Phillips screwdriver to remove the two horn housing cover screws.
5. Replace the battery with a 9V battery only.
6. (If desired) Change the Hi/Lo switch position (Fig. 5, Detail A).
7. Replace the horn housing cover and screws.
8. (To be performed if horn was removed) Orient the horn at the top of the Universal Stopper cover,
and replace the button head screw.
9. Remove the Service Pin and horn should sound. Close cover and horn should silence.
Options Available
Part Number Description Flush Surface Backbox Backbox
STI-1314 Universal Stopper Backplate X X
STI-6602* Horn Assembly X X X
SUB-319 Wiring harness for remote power X X X
SUB-65 Breakaway Seal (qty. 5) X X X X
EA135 Service Pin X X X
Enclosed
17. (When using HORN option) Remove the Service Pin and horn should sound. Close cover and
horn should silence.
18. (When using HORN option) To test switch activation, open cover and horn should sound. Close
cover and horn should silence. When performing annual battery test/replacement or whenever
servicing alarm system, insert the Service Pin into the Service Pin Receptor to prevent horn
from sounding. Remember to remove Service Pin to return to normal operation.
19. When using LOCKING TAB feature (not for use in fire or emergency signaling applications), insert
the Breakaway Seal SUB-65 completely into the Locking Tab. Then insert the tip of the Breakaway
Seal into the hole in the Breakaway Seal from the side that reads “ENTER.” Pull the pin through
until tight. Not for use with fire pull stations.
*Available in red, green, blue, yellow, white or black.
- 6 -
Flush
Enclosed
