Wiring Diagrams
The supply cord and internal wiring within the terminal box are routed
and secured to ensure compliance with the electrical standard EN 60335-1.
It is essential that any disturbance of this internal wiring is avoided and the
factory routing and securing of all internal wiring is always maintained.
NOISE
The equivalent continuous A-weighted sound pressure level from the pumpset does not
exceed 70 dB(A) at a distance of one metre.
COMMISSIONING
WARNINGS:
 The motor casing can become very hot under normal operating
conditions, care should be taken to ensure it cannot be touched
during operation.

Do not run pump without guards and terminal box lid correctly fitted.
 The pump chamber must be full of liquid at all times. Seal damage
will result if the pump runs dry.
START WINDING
E
CAPACITOR
GR
EEN
/YE
LLOW
BL
AC
K
BL
AC
K
BR
OWN
WH
IT
E
BL
UE
BLU
E
BROWN
230V, 1 phase, 50Hz supply
THAME, LODDON & X201 RANGE
KENNET K7-2, K9-2 & K12-2 RANGE
230V, 1 phase, 50Hz supply
400V,3 phase, 50Hz supply
KENNET K9-2 & K12-2
ANY TWO SUPPLY LEADS
TO REVERSE ROTATION INTERCHANGE
L3 L1 L2
W V U
RE
D
YE
LL
O
W
MOTOR
BL
UE
BL
AC
K
WH
IT
E
BR
O
W
N
E
G
REE
N/YE
LL
O
W
230 VAC/1PH/50Hz
SUPPLY
L N E
BR
O
W
N
BLU
E
GRE
EN
/YELLOW
BR
OWN
LIN
K W
IR
E
(B
LU
E)
BL
AC
K
CAPA
CI
TO
R
MAIN WINDING
BLUE
THERMOTRIP
Fig. 16
Fig. 17
Fig. 18
