- 12 -
7 TECHNICAL SPECIFICATION
Model LS5
Electrical
Volts/Ph/Frequency 230/1/50
Power consumed 460 Watts
Full load current 2.0 Amps
Rating Continuous
Max. No Starts per hour 60
Enclosure IPX4
Fuse Size 5 Amp
Mechanical
Max flow 120 litres/min
Max head (closed valve) 7.7 metres
Max liquid temperature (continuous duty) 50 o C
Max liquid temperature
(short term duty eg. washing machine)
70 o C
Min liquid temperature 4 o C
Max ambient air temperature 40 o C
Max noise level 60 dB
Dimensions
Length 413 mm
Width 180 mm
Height (excluding flexible hoses) 278 mm
Gross Weight (packed) 8.9 Kg
Connections
Inlet(s) Standard
Washing machine (x1)
40 mm (1½ ") dia.
20 mm/G ¾ Elbow
connection
Outlet 32 mm (1¼ ") dia.
Connecting cable 1.5 metres
Stuart Turner reserve the right to amend the specification in line with its policy of
continuous development of its products.
