Page 18
- 18 -
Cont ...
7 TECHNICAL
SPECIFICATION (Single Models)
Model
S2.0 bar Single
S3.0 bar Single
S4.5 bar Single
Electrical
Power supply
Volts/phase freqency
230/1/50
230/1/50
230/1/50
Enclosure
IPX4
IPX4
IPX4
Type of motor
Induction
Induction
Induction
Power consumption
245 Watts
385 Watts
555 Watts
Full load current
1.1 Amps
1.7 Amps
2.4 Amps
Rating
Continuous (S1) @
9 l/min & above
Continuous (S1) @
9 l/min & above
Continuous (S1) @
9 l/min & above
Max. No Starts per hour
60
60
60
Mechanical
Max inlet head
8 metres
14 metres
14 metres
Max head (closed valve)
20 metres
30 metres
45 metres
Max working pressure*
600 kPa (6.0 bar)
600 kPa (6.0 bar)
600 kPa (6.0 bar)
Max ambient air temperature
40
o
C
40
o
C
40
o
C
Max water temperature**
65
o
C
65
o
C
65
o
C
Min water temperature
4
o
C
4
o
C
4
o
C
P
ump
Dimensions
Length
200 mm
200 mm
200 mm
Width
126 mm
126 mm
126 mm
Height (excluding flexible hoses)
202 mm
202 mm
202 mm
Weight (incl. flexible hoses)
6.5 Kg
6.5 Kg
7.1 Kg
Pump connections:
Inlet
G ¾
G ¾
G ¾
Outlet
G ¾
G ¾
G ¾
