PRESSURE SWITCH
BELT GUARD
GAS VALVE
RETAINER SPRING
AIR SHUTTERS
PILOT ASSY.
MANIFOLD
Figure 19 - Internal Furnace Assem-
bly
MAIN
BURNERS
Figure 18 - Combustion Chamber
IDENTIFICATION OF PARTS
Figure 20 - Separated Combustion Unit Heater
POWER VENT ASSY.
POWER VENT MOTOR
BLOWER MOTOR
AIR INLET
GAS SUPPLY INLET
A – Heat Exchanger
B – Flue Collector
C – Burner Compartment
