<9. General Specifications>
9-4
IM 01C25F01-01E
Communication Requirements “◊”
(Safety approvals may affect electrical
requirements.)
BRAIN
Communication Distance
Up to 2 km (1.25 miles) when using CEV
polyethylene-insulated PVC-sheathed cables.
Communication distance varies depending on
type of cable used.
Load Capacitance
0.22 μF or less
Load Inductance
3.3 mH or less
Input Impedance of communicating device
10 kΩ or more at 2.4 kHz.
HART
Communication Distance
Up to 1.5 km (1 mile) when using multiple
twisted pair cables. Communication distance
varies depending on type of cable used.
Use the following formula to determine cable
length for specific applications:
L= –
65 × 10 6
(R × C)
(C
f + 10,000)
C
Where:
L = length in meters or feet
R = resistance in Ω (including barrier
resistance)
C = cable capacitance in pF/m or pF/ft
C
f
= maximum shunt capacitance of receiving
devices in pF/m or pF/ft
EMC Conformity Standards ,
EN61326-1 Class A, Table2 (For use in industrial
locations)
EN61326-2-3
 Physical Specifications
Wetted Parts Materials
Diaphragm, Process Connector
Refer to “Model and Suffix Code.”
Non-wetted Parts Materials
Housing
Low copper cast aluminum alloy with
polyurethane paint or ASTM CF-8M stainless
steel
Degrees of Protection
IP66/IP67, NEMA TYPE 4X
Pipe
Polypropylene
Cover O-rings
Buna-N, fluoro-rubber (option)
Nameplate and tag
316SST (including /N4 wired tag)
Fill Fluid
Silicone, Fluorinated oil (option)
Weight
Capsule A, B and C: 1. 2kg (2.6 lb)*
Capsule D: 1.4 kg (3.1 lb)*
*: Without integral indicator and mounting bracket.
Add 1.5 kg (3.3lb) for Amplifier housing code 2.
Connections
Refer to “Model and Suffix Code.”
