<9. General Specifications>
9-2
IM 01C25F01-01E
Failure Alarm “◊”
Output status at CPU failure and hardware
error;
Up-scale: 110%, 21.6 mA DC or more
(standard)
Down-scale: –5%, 3.2 mA DC or less
Note: Applicable for Output signal code D and E
Damping Time Constant (1st order)
Amplifier damping time constant is adjustable
from 0 to 100.00 seconds and added to
response time.
Note: For BRAIN protocol type, when amplifier damping
is set to less than 0.5 seconds, communication
may occasionally be unavailable during the
operation, especially while output changes
dynamically. The default setting of damping
ensures stable communication.
Update Period “◊”
45 ms
Zero Adjustment Limits
Zero can be fully elevated or suppressed, within
the lower and upper range limits of the capsule.
External Zero Adjustment “◊”
External Zero is continuously adjustable with
0.01% incremental resolution of span. Re-range
can be done locally using the digital indicator
with range-setting switch.
Integral Indicator (LCD display)
5-digit Numerical Display, 6-digit Unit Display
and Bar graph.
The indicator is configurable to display one or
up to four of the following variables periodically.;
Pressure in %, Scaled pressure, pressure in
Engineering unit.
See “Setting When Shipped” for factory setting.
Burst Pressure Limits
EJ510 and EJ530
Capsule Pressure
A, B, C 30 MPa (4350 psi)
D 132 MPa (19100 psi)
EJX610A and EJX630A
Capsule Pressure
A, B, C 50 MPa (7200 psi)
D 182 MPa (26300 psi)
 Normal Operating Condition
(Selected features may affect limits.)
Ambient Temperature Limits
–40 to 85°C (–40 to 185°F)
–30 to 80°C (–22 to 176°F) with LCD display
Process Temperature Limits
–40 to 120°C (–40 to 248°F)
Ambient Humidity Limits
0 to 100% RH
Working Pressure Limits (Silicone oil)
Maximum Pressure Limits
Pressure
Capsule EJ510 EJ530
A 200 kPa abs (29 psia) 200 kPa (29 psig)
B 2 MPa abs (290 psia) 2 MPa (290 psig)
C 10 MPa abs (1450 psia) 10 MPa (1450 psig)
D 50 MPa abs (7200 psia) 50 MPa (7200 psig)
Pressure
Capsule EJX610A EJX630A
A 200 kPa abs (29 psia) 200 kPa (29 psi)
B 2 MPa abs (290 psia) 2 MPa (290 psi)
C 10 MPa abs (1450 psia) 10 MPa (1450 psi)
D 70 MPa abs (10150 psia) 70 MPa (10150 psi)
Minimum Pressure Limit
See graph below
-40
(-40)
0
(32)
40
(104)
80
(176)
120
(248)
0.1(0.75)
0.13(1)
1(7.5)
100(750)
10(75)
2.7(20)
0.01(0.075)
0.013(0.1)
85 (185)
(mmHg abs)
Working
pressure
kPa abs
Applicable range
Process temperature °C(°F)
F0901.ai
Figure 9.1 Working Pressure and Process
Temperature [For EJ510 and
EJX610A]
