16 PC100 Series Operation Manual
1010-1022 Rev. 01
Jumper Definition Representation in Diagram
jumper block
jumper cap
2 pin jumper closed (enabled)
3 pin jumper
2-3 pin closed (enabled)
Jumper Block
1-2 pin closed (enabled)
