PLEASE READ THIS MANUAL CAREFULLY
This manual contains useful ideas for obtaining the most efficient operation from your
Ramsey Winch, and safety procedures one needs to know before operating a Ramsey
Winch. Do not operate this winch until you have carefully read and understand the
"WARNING" and "OPERATION" sections of this manual.
WARRANTY INFORMATION
Ramsey Winches are designed and built to exacting specifications. Great care and skill
go into every winch we make. If the need should arise, warranty procedure is outlined
on the back of your self-addressed postage paid warranty card. Please read and fill out
the enclosed warranty card and send it to Ramsey Winch Company. If you have any
problems with your winch, please follow instructions for prompt service on all warranty
claims. Refer to back page for limited warranty.
SPECIFICATIONS*
NOTE: The rated line pulls shown are for the winch only. Consult the wire rope manufac-
turer for wire rope ratings.
3
Rated Line Pull (lbs.) ………………………………………………… 8,000
(Kg.) ………………………………………………… 3,620
Gear Reduction 5.1:1
………………………………………114 lbs. (51.8 Kg)
1 2 3 4 5
lbs. 8,000 6,800 5,900 5,200 4,700
Kg. 3,620 3,080 2,670 2,350 2,120
ft. 15 35 60 85 115
m 4 10 18 25 34
FPM 50 58 67 76 84
MPM 15.2 17.6 20.3 23.1 25.5
…………………………………………………………
Weight (without cable)
* These specifications are based on recommended wire rope of 3/8" (10mm)
galvanized aircraft cable, or EIPS cable and a 15.5 cu.in./Rev. motor.
LAYER OF CABLE
* Rated line pull
per layer
* Line Speed
(at 15 GPM)
Cable Capacity
