Poly-Tex KOOL HOUSE - Manual (Page 5)

SCREW SELF-DRILLING
#12-14 x 3/4"
(NB1802)
SELF DRILLING SCREW
#12-14 x 1 1/2"
(NB1805)
5/16"x1-1/4"
CARRIAGE BOLT
(NB1832)
5/16" LOCK WASHER
(NB1862)
5/16" HEX NUT
(NB1872)
5/16" FLAT WASHER
(NB1886)
1/4" x 1-1/2"
LAG SCREW
(NB1810)
WIGGLE BASE
(WWBASE9)
WIGGLE WIRE
(WIGLWIRE)
28IN CHAIN FOR
ROLL-UP GUIDE
(RC1307)
ROLL-UP
TUBE CLIP
(RC1010)
GEARBOX
EXTENSION
(RC1009)
L-FLASHING
(PT3926)
3/8" x 3 3/4"
ANCHOR BOLT
(NB1929)
FLAT WASHER 1-1/8"
NEOPRENE
(NB1869)
CRADLE WITH
"S" HOOK
(RC1310)
RAIL SIDE 5
(RC1306)
GUIDE MOUNT
BRACKET
(RC1301)
ROLL-UP CURTAIN
GEARBOX GUIDE
(RC1305)
BRACKET WITH
"S" HOOK
(RC1311)
ROLL UP UNIT
MV1000
PARTS IDENTIFICATION - SHEET 3
THREE
REV: AC-120529 610578-1
KOOL HOUSE
PARTS IDENTIFICATION - OPTIONAL ROLL-UP CURTAINS
1/4" POLYESTER
ROPE
(RS5049)
