Poly-Tex KOOL HOUSE - Manual (Page 13)

OPTIONAL ROLL-UP CURTAIN INSTRUCTIONS
ELEVEN
REV: AC-120529 610576-1
KOOL HOUSE
#12-14 x 1-1/2" SELF
DRILLING SCREW
#12-14 x 3/4" SELF
DRILLING SCREW
ROLL FORM RAIL
ROLL FORM RAIL
INSTRUCTIONS
16. RAISE CURTAIN ABOUT HALF WAY UP. SET CRADLES JUST INSIDE THE
SIDE GUIDE ON BOTH ENDS OF THE HOUSE AND EVERY 12' THEREAFTER.
ATTACH CRADLES USING #12 x 3/4" SELF DRILLING SCREWS.
17. ROPE BRACKETS ARE PLACED EVERY 12' BETWEEN THE CRADLES WITH
LARGE HOLE FACING DOWN. ATTACH USING #12 x 1-12" SELF DRILLING
SCREW.
18. ROLL CURTAIN DOWN SO IT RESTS IN THE CRADLES. SECURE GUIDE
MOUNTING BRACKET TO THE GROUND USING 18" SPIKES.
19. THREAD ROPE THROUGH THE CRADLES & ROPE BRACKETS, CONTINUE
TO THE END OF THE HOUSE. ROPE SHOULD BE KEPT FAIRLY TIGHT.
18" SPIKE
GUIDE MOUNTING
BRACKET
BRACKET WITH
"S" HOOK
CRADLE WITH
"S" HOOK
