Poly-Tex KOOL HOUSE - Manual (Page 11)

OPTIONAL ROLL-UP CURTAIN INSTRUCTIONS
NINE
REV: AC-120529 610574-1
KOOL HOUSE
2"
2"
74"
POLY CURTAIN
LENGTH AS
REQUIRED
POLY CURTAIN
#12-14 x 3/4" SELF
DRILLING SCREW
CF1014
INSTRUCTIONS
9. ASSEMBLE BOTTOM TUBE. SECURE WITH #12-14 x 3/4" SELF
DRILLING SCREWS.
10. INSTALL ROLL UP CURTAIN POLY. EXTEND CURTAIN POLY ABOUT
2" BEYOND HOOP AND ABOUT 2" ABOVE UPPER RAIL.
KEEP AS EVEN AS POSSIBLE. AFTER POLY IS SECURE MEASURE
DOWN 74" FROM TOP RAIL AND PLACE A MARK ON POLY USING
A MARKING PEN.
11. USE THE MARK TO ALIGN ROLL UP TUBE WHILE FASTENING TUBE
CLIPS. FASTEN CURTAIN TO TUBE USING CLIPS EVERY 3' KEEPING
TUBE STRAIGHT WITH MARKS.
TUBE CLIP
MARK FOR
ROLL UP TUBE
