LCD-KIT
Page 48
Factory Reset Select
Auto Adjust Select
Auto Color Select
Gamma Off, On
Exit Menu Exit Select
Table 6-1: OSD Menus
6.2 Using the OSD
OSD menu options are described below.
6.2.1 Main Display Features
Main display features are shown in Figure 6-3.
Figure 6-3: Main Display Features
Brightness
The brightness option adjusts the brightness of screen. This function
adjusts the offset value of ADC. Setting this value too high or too low
will affect the quality of image. When the auto- dimming function is
turned on, the brightness control is not effective.
Contrast
This function adjusts the gain value of ADC. Adjusting this value too
high or too low will worsen the quality of image.
Clock Adjusts the width of the display screen.
