ƒ 9~36 V DC power connector
2.3.5 Variant 4 Connectors
The following is a list of the bottom panel peripheral device connectors used on the
LCD-KIT121GXM, LCD-KIT150GM, LCD-KIT170GM and LCD-KIT190GM series LCD
monitor.
ƒ VGA connector
ƒ DVI-D connector
ƒ 9~36 V DC power connector
2.4 Physical Dimensions
The following sections describe the physical dimensions for each model of the LCD-KIT
series LCD monitor.
2.4.1 General Physical Dimensions
General physical dimensions for the LCD-KIT series LCD monitors are shown in
3
Table
2-2.
Model Width (mm) Height (mm) Depth (mm)
LCD-KIT190G 427.9 327.0 48.7
LCD-KIT170GS 390.4 299.6 46.3
LCD-KIT150G 364.1 262.1 41.3
LCD-KIT121G/GX 294.0 240.7 41.3
LCD-KIT104GH 244.5 209.0 43.4
LCD-KIT84GH 234.0 147.0 44.0
LCD-KIT65GH 203.4 121.0 34.0
Table 2-2: General Physical Dimensions
