LCD-KIT
Page 20
2.5 Mounting Options
Each LCD-KIT series LCD monitor has mounting holes located on the mounting bracket.
Table 2-3 details the number of mounting holes for each model of the LCD-KIT series LCD
monitor. Refer to Section
Model
No. of Round Holes - Size
No. of Slotted Holes
LCD-KIT190G
6 – 4 mm diameter
8
LCD-KIT170G
6 – 4.5 mm diameter
8
LCD-KIT150G
6 – 4.5 mm diameter
8
LCD-KIT121G/GX 4 – 3.5 mm diameter
-
LCD-KIT104GH
4 – 3.5 mm diameter
-
LCD-KIT84GH
4 – 3.5 mm diameter
4
LCD-KIT65GH
4 – 3.5 mm diameter
4
Table 2-3: Mounting Holes
