PPC-5152-D525 Falt-bezel Panel PC

Page 9

1.4.4 Top Panel

The top panel of the flat panel PC have some vents for ventilation and slots for installing

the panel mounting clamps. The model with wireless LAN module also includes two

wireless LAN antenna connectors on the top panel (

556

Figure 1-5

).

Figure 1-6: Top View

1.4.5 Rear Panel

The rear panel has retention screw holes that support a wall-mounting bracket. The rear

panel also provides access to the internal USB port.

Figure 1-7: Rear View
