PPC-5152-D525 Falt-bezel Panel PC

Page 5

Figure 1-2: Front View

1.4.1.1 LED Indicators

The LED indicators on the front panel of the PPC-5152-D525 are shown below.

Figure 1-3: LED Indicators

The descriptions of each LED indicator are listed below.

LED Indicator

Description

Power

Power on.
