1 battery connector (bt1), 2 fan connector (fan1), 3 gpio87 to sio connector (sw2) – IEI Integration IOPS-Q67_H61 User Manual

Page 57: Table 6-1: peripheral interface connectors, Table 6-2: battery connector (bt1) pinouts, Table 6-3: fan connector (fan1) pinouts, Table 6-4: gpio87 to sio connector (sw2) pinouts

IOPS-Q67/H61 Pluggable Module PC

Page 47

Connector

Type

Label

PCIe Mini card slots

Full-size PCIe Mini card slot

JP2

SD card slot

CN1

SO-DIMM connector

DIMM1

USB DOM connector

8-pin header

USB2

Table 6-1: Peripheral Interface Connectors

6.2.1 Battery Connector (BT1)

6.2.2 Fan Connector (FAN1)

6.2.3 GPIO87 to SIO Connector (SW2)

PIN NO.

DESCRIPTION

1 BATT

2 GND

Table 6-2: Battery Connector (BT1) Pinouts

PIN NO.

DESCRIPTION

1 GND

2 +12V

3 FB

4 PWM

Table 6-3: Fan Connector (FAN1) Pinouts

PIN NO.

DESCRIPTION

1 NC

2 GPIO

3 GND

4 NC

Table 6-4: GPIO87 to SIO Connector (SW2) Pinouts
